Events Types
AP Mesh Events
TABLE 240 MAP downlink connected event (continued)
Event
Attribute
Displayed on the web
interface
Description

MAP downlink connected to EMAP

TABLE 241 MAP downlink connected to EMAP event
Event
Event Type
Event Code
Severity
Attribute
Displayed on the web
interface
Description

MAP downlink disconnected from EMAP

TABLE 242 MAP downlink disconnected from EMAP event
Event
Event Type
Event Code
Severity
Attribute
Displayed on the web
interface
Description

RAP downlink connected to MAP

TABLE 243 RAP downlink connected to MAP event
Event
Event Type
Event Code
Severity
Attribute
Displayed on the web
interface
Description
168
MAP downlink connected
"mapMac="xx:xx:xx:xx:xx:xx"
MAP [{apName&&apMac}] downlink connected
This event occurs when MAP downlink connects to the AP.
MAP downlink connected to EMAP
mapDlinkConnectWitheMap
413
Informational
"mapMac"="xx:xx:xx:xx:xx:xx", "emapMac="xx:xx:xx:xx:xx:xx"
MAP [{apName&&apMac}] accepted connection from eMAP
[{emapName&&emapMac}]
This event occurs when MAP accepts the connection from Ethernet Mesh AP.
MAP downlink disconnected from EMAP
mapDlinkDisconnectWitheMap
414
Informational
"mapMac"="xx:xx:xx:xx:xx:xx", "emapMac="xx:xx:xx:xx:xx:xx"
eMAP [{emapName&&emapMac}] disconnected from MAP [{apName&&apMac}]
This event occurs when Ethernet Mesh AP disconnects from MAP.
RAP downlink connected to MAP
rapDlinkConnectWithMap
416
Informational
"rapMac"="xx:xx:xx:xx:xx:xx", "mapMac="xx:xx:xx:xx:xx:xx"
RAP [{apName&&apMac}] accepted connection from MAP
[{mapName&&mapMac}]
This event occurs when the root access point (RAP) accepts MAP connection.
