MAP uplink connected to EMAP

TABLE 244 MAP uplink connected to EMAP event
Event
Event Type
Event Code
Severity
Attribute
Displayed on the web
interface
Description

MAP uplink disconnected from EMAP

TABLE 245 MAP uplink disconnected from EMAP event
Event
Event Type
Event Code
Severity
Attribute
Displayed on the web
interface
Description

MAP uplink connected to RAP

TABLE 246 MAP uplink connected to RAP event
Event
Event Type
Event Code
Severity
Attribute
Displayed on the web
interface
Description
Ruckus SmartCell Gateway 200 Virtual SmartZone High Scale and SmartZone 300 Alarm and Event Reference Guide
Part Number: 800-71565-001 Rev A
MAP uplink connected to EMAP
mapUlinkConnectToeMap
417
Informational
"mapMac"="xx:xx:xx:xx:xx:xx", "emapMac="xx:xx:xx:xx:xx:xx",
"rssi"="xx", "meshDepth"="x"
MAP [{apName&&apMac}] connected to eMAP [{emapName&&emapMac}] with
RSSI [{rssi}] across [{meshDepth}] links
This event occurs when MAP successfully connects to Ethernet Mesh AP with
received signal strength indicator (RSSI) (across links).
MAP uplink disconnected from EMAP
mapUlinkDisconnectToeMap
418
Informational
"mapMac"="xx:xx:xx:xx:xx:xx", "emapMac="xx:xx:xx:xx:xx:xx"
MAP [{apName&&apMac}] disconnected from eMAP [{emapName&&emapMac}]
This event occurs when MAP disconnects from Ethernet Mesh AP.
MAP uplink connected to RAP
mapUlinkConnectToRap
419
Informational
"mapMac"="xx:xx:xx:xx:xx:xx", "rootMac="xx:xx:xx:xx:xx:xx",
"rssi"="xx", "meshDepth"="x"
MAP [{apName&&apMac}] connected to RAP [{rootName&&rootMac}] with RSSI
[{rssi}] across [{meshDepth}] links
This event occurs when MAP connects to RAP with RSSI (across links).
Events Types
AP Mesh Events
