Alarm Types
IPMI Alarms
TABLE 111 ipmiThempHSBP alarm (continued)
Alarm
Aggregation Policy
Auto Clearance
Attribute
Displayed on the web
interface
Description
Recommended Actions

ipmiFan

TABLE 112 ipmiFan alarm
Alarm
Alarm Type
Alarm Code
Severity
Aggregation Policy
Auto Clearance
Attribute
Displayed on the web
interface
Description
Recommended Actions

ipmiPower

TABLE 113 ipmiPower alarm
Alarm
Alarm Type
Alarm Code
Severity
Aggregation Policy
Auto Clearance
Attribute
Displayed on the web
interface
Description
Recommended Actions
112
ipmiThempHSBP
From the event code 908 an alarm is raised for every event. A single event
triggers a single alarm.
The alarm code is auto cleared with the event code 933.
"id"="x", "status"="xxxxx", "nodeMac"="xx:xx:xx:xx:xx:xx"
Hot swap backplane temperature [{status}] on control plane [{nodeMac}]
This alarm is triggered when the control plane's hot swap backplane shows the
status as either an increase/decrease in temperature in the range of 9
0
55 Celsius. The default threshold is 55
Check the fan module. Decrease the ambient temperature if the fan module is
working.
ipmiFan
ipmiFan
909
Major
From the event code 909 an alarm is raised for every event. A single event
triggers a single alarm.
The alarm code is auto cleared with the event code 934.
"id"="x", "status"="xxxxx", "nodeMac"="xx:xx:xx:xx:xx:xx"
System fan [{id}] module [{status}] on control plane [{nodeMac}]
This alarm is triggered when the control plane's fan module status is shown.
Replace the fan module.
ipmiPower
ipmiPower
910
Major
From the event code 910 an alarm is raised for every event. A single event
triggers a single alarm.
The alarm code is auto cleared with the event code 935.
"id"="x", "status"="xxxxx", "nodeMac"="xx:xx:xx:xx:xx:xx"
Power supply [{id}] AC power input [{status}] on control plane [{nodeMac}]
This alarm is triggered when the control plane's power supply status is shown as
a low/high input.
Replace the power supply cord.
0
C.
Ruckus SmartCell Gateway 200 Virtual SmartZone High Scale and SmartZone 300 Alarm and Event Reference Guide
0
Celsius to
Part Number: 800-71565-001 Rev A
