FC 300 Programming Guide

3.13 Parameters: Ethernet

3.13.1 12-0* IP Settings
12-00 IP Address Assignment
Option:
[0] * Manual
[1] DHCP
[2] BOOTP
12-01 IP Address
Range:
[000.000.000.000
255.255.255.255]
12-02 Subnet Mask
Range:
[000.000.000.000
255.255.255.255]
12-03 Default Gateway
Range:
[000.000.000.000
255.255.255.255]
12-04 DHCP Server
Range:
[000.000.000.000
255.255.255.255]
NB!
A power-cycle is necessary after setting the IP parameters manually.
12-05 Lease Expires
Range:
[dd:hh:mm:ss]
12-06 Name Servers
Option:
[0] Primary DNS
[1] Secondary DNS
12-07 Domain Name
Range:
Blank [0-19 characters]
12-08 Host Name
Range:
Blank [0-19 characters]
Function:
Selects the IP Address assignment method.
IP-address can be set in par. 12-01 IP Address.
IP-address is assigned via DHCP server.
IP-address is assigned via BOOTP server.
Function:
- Configure the IP address of the option. Read-only if par. 12-00 set to DHCP or BOOTP.
Function:
- Configure the IP subnet mask of the option. Read-only if par. 12-00 set to DHCP or BOOTP.
Function:
– Configure the IP default gateway of the option. Read-only if par. 12-00 set to DHCP or BOOTP.
Function:
– Read only. Displays the IP address of the found DHCP or BOOTP server.
Function:
Read only. Displays the lease-time left for the current DHCP-assigned IP address.
Function:
IP addresses of Domain Name Servers. Can be automatically assigned when using DHCP.
Function:
Domain name of the attached network. Can be automatically assigned when using DHCP.
Function:
Logical (given) name of option.
®
