Parameter Descriptions

3.13 Parameters: 12-** Ethernet

3.13.1 12-0* IP Settings
12-00 IP Address Assignment
Option: Function:
Selects the IP Address assignment method.
[0] Manual IP-address can be set in12-01 IP Address IP Address.
*
[1] DHCP IP-address is assigned via DHCP server.
[2] BOOTP IP-address is assigned via BOOTP server.
12-01 IP Address
Range: Function:
[000.000.000.000 - Configure the IP address of the
255.255.255.255] option. Read-only if 12-00 IP Address
Assignment set to DHCP or BOOTP.
12-02 Subnet Mask
Range: Function:
[000.000.000.000 - Configure the IP subnet mask of the
255.255.255.255] option. Read-only if 12-00 IP Address
Assignment set to DHCP or BOOTP.
12-03 Default Gateway
Range: Function:
[000.000.000.000 – Configure the IP default gateway of
255.255.255.255] the option. Read-only if 12-00 IP
Address Assignment set to DHCP or
BOOTP.
12-04 DHCP Server
Range:
[000.000.000.000 – Read only. Displays the IP address
255.255.255.255] of the found DHCP or BOOTP server.
NOTE
A power-cycle is necessary after setting the IP parameters
manually.
12-05 Lease Expires
Range: Function:
[dd:hh:mm:ss] Read only. Displays the lease-time left for the
current DHCP-assigned IP address.
12-06 Name Servers
Option: Function:
IP addresses of Domain Name Servers. Can be
automatically assigned when using DHCP.
[0] Primary DNS
[1] Secondary DNS
12-07 Domain Name
Range: Function:
Blank [0-19 characters] Domain name of the attached network.
Can be automatically assigned when
using DHCP.
FC 300 Programming Guide
Function:
®
MG.33.MB.02 - VLT is a registered Danfoss trademark
12-08 Host Name
Range: Function:
Blank [0-19 characters] Logical (given) name of option.
12-09 Physical Address
Range: Function:
[00:1B:08:00:00:00 – 00:1B: Read only Displays the Physical
08:FF:FF:FF] (MAC) address of the option.
3.13.2 12-1* Ethernet Link Parameters
12-1* Ethernet Link parameters
Option: Function:
Applies for whole parameter group.
[0] Port 1
[1] Port 2
12-10 Link Status
Option: Function:
Read only. Displays the link status of the Ethernet
ports.
[0] No link
[1] Link
12-11 Link Duration
Option: Function:
Link Duration Port 1 Read only. Displays the duration of
(dd:hh:mm:ss) the present link on each port in
dd:hh:mm:ss.
12-12 Auto Negotiation
Option: Function:
Configures Auto Negotiation of Ethernet link parameters,
for each port: ON or OFF.
[0] Off Link Speed and Link Duplex can be configured in 12-13 Link
Speed and 12-14 Link Duplex.
[1] On
12-13 Link Speed
Option: Function:
Forces the link speed for each port in 10 or 100
Mbps. If 12-12 Auto Negotiation is set to: ON, this
parameter is read only and displays the actual link
speed. "None" is displayed if no link is present.
[0] None
*
[1] 10 Mbps
[2] 100 Mbps
12-14 Link Duplex
Option: Function:
Forces the duplex for each port to Full or Half
duplex. If 12-12 Auto Negotiation is set to: ON,
this parameter is read only.
[0] Half duplex
[1] Full duplex
*
