FC 300 Programming Guide
[173] ft WG
[180] HP
0-31 Min Value of User-defined Readout
Range:
0.00 Cus- [Application dependant]
tomReadou-
tUnit*
0-32 Custom Readout Max Value
Range:
100.00 Cus- [Application dependant]
tomReadou-
tUnit*
0-37 Display Text 1
Range:
0* [0 - 0 ]
0-38 Display Text 2
Range:
0* [0 - 0 ]
0-39 Display Text 3
Range:
0* [0 - 0 ]
3.2.6 LCP Keypad, 0-4*
Enable, disable and password protect individual keys on the LCP.
0-40 [Hand on] Key on LCP
Option:
[0] Disabled
[1] * Enabled
[2] Password
[3] Hand Off/On
[4] Hand Off/On w. Passw.
Function:
This parameter sets the min. value of the custom defined readout (occurs at zero speed). Only
possible to set different from 0 is when selecting a linear unit in par. 0-30
Readout . For Quadratic and Cubic units the minimum value will be 0.
Function:
This parameter sets the max value to be shown when the speed of the motor has reached the set
Motor Speed High Limit [RPM]
value for par. 4-13
Motor Speed Unit
on setting in par. 0-02
Function:
Enter a text which can be viewed in the graphical display by selecting Display Text 1 [37] in par.
0-20, 0-21, 0-22, 0-23 or 0-24.
Function:
Enter a text which can be viewed in the graphical display by selecting Display Text 2 [38] in par.
0-20, 0-21, 0-22, 0-23 or 0-24.
Function:
Enter a text which can be viewed in the graphical display by selecting Display Text 3 [39] in par.
0-20, 0-21, 0-22, 0-23 or 0-24.
Function:
No effect when [Hand on] is pressed. Select [0] Disabled to avoid accidental start of the drive in
Hand on mode.
The LCP switches to Hand on mode directly when [Hand on] is pressed.
After pressing [Hand on] a password is required. If par. 0-40 is in included in
Personal Menu Password
define the password in par. 0-65,
Main Menu Password
0-60,
When [Hand on] is pressed once, the LCP switches to
switches to Hand on mode.
Same as [3] but a password is required (see [2]).
®
MG.33.M8.02 - VLT is a registered Danfoss trademark
3 Parameter descriptions
Motor Speed High Limit [Hz]
or par. 4-14
).
. Otherwise define the password in par.
Off mode. When pressed again, the LCP
Unit for User-defined
3
(depends
My Personal Menu
,
