3 Parameter descriptions
5-71 Term 32/33 Encoder Direction
Option:
[0] * Clockwise
[1] Counter clockwise
3
This parameter cannot be adjusted while the motor is running.
3.7.9 5-9*Bus Controlled
This parameter group selects digital and relay outputs via a fieldbus setting.
5-90 Digital & Relay Bus Control
Range:
0* [0 - 2147483647 ]
Bit 0
Bit 1
Bit 2
Bit 3
Bit 4
Bit 5
Bit 6
Bit 7
Bit 8
Bit 9-15
Bit 16
Bit 17
Bit 18
Bit 19
Bit 20
Bit 21
Bit 22
Bit 23
Bit 24-31
5-93 Pulse Out #27 Bus Control
Range:
0.00 %* [0.00 - 100.00 %]
5-94 Pulse Out #27 Timeout Preset
Range:
0.00 %* [0.00 - 100.00 %]
5-95 Pulse Out #29 Bus Control
Range:
0.00 %* [0.00 - 100.00 %]
114
Function:
Change the detected encoder rotation direction without changing the wiring to the encoder.
Sets channel A 90° (electrical degrees) behind channel B upon clockwise rotation of the encoder
shaft.
Sets channel A 90° (electrical degrees) ahead of channel B upon clockwise rotation of the encoder
shaft.
Function:
This parameter holds the state of the digital outputs and relays that is controlled by bus.
A logical '1' indicates that the output is high or active.
A logical '0' indicates that the output is low or inactive.
Digital Output Terminal 27
Digital Output Terminal 29
Digital Output Terminal X 30/6
Digital Output Terminal X 30/7
Relay 1 output terminal
Relay 2 output terminal
Option B Relay 1 output terminal
Option B Relay 2 output terminal
Option B Relay 3 output terminal
Reserved for future terminals
Option C Relay 1 output terminal
Option C Relay 2 output terminal
Option C Relay 3 output terminal
Option C Relay 4 output terminal
Option C Relay 5 output terminal
Option C Relay 6 output terminal
Option C Relay 7 output terminal
Option C Relay 8 output terminal
Reserved for future terminals
Function:
Set the output frequency transferred to the output terminal 27 when the terminal is configured as
'Bus Controlled' in par. 5-60
Function:
Set the output frequency transferred to the output terminal 27 when the terminal is configured as
'Bus Ctrl Timeout' in par. 5-60
Function:
Set the output frequency transferred to the output terminal 29 when the terminal is configured as
'Bus Controlled' in par. 5-63
This parameter only applies for FC 302.
MG.33.M8.02 - VLT
Terminal 27 Pulse Output Variable
Terminal 27 Pulse Output Variable
Terminal 29 Pulse Output Variable
®
is a registered Danfoss trademark
FC 300 Programming Guide
[45].
[48]. And a time-out is detected.
