Danfoss VLT AutomationDrive FC 300 Programming Manual page 103

3 Parameter descriptions
[123] Start command active
[124] Running reverse
[125] Drive in hand mode
[126] Drive in auto mode
3
5-30 Terminal 27 Digital Output
Option:
[0] * No operation
5-31 Terminal 29 Digital Output
Option:
[0] * No operation
5-32 Term X30/6 Digi Out (MCB 101)
Option:
[0] * No operation
[1] Control ready
[2] Drive ready
[3] Drive rdy/rem ctrl
[4] Enable / no warning
[5] Running
[6] Running / no warning
[7] Run in range/no warn
[8] Run on ref/no warn
[9] Alarm
[10] Alarm or warning
[11] At torque limit
[12] Out of current range
[13] Below current, low
[14] Above current, high
[15] Out of speed range
[16] Below speed, low
[17] Above speed, high
[18] Out of feedb. range
[19] Below feedback, low
[20] Above feedback, high
[21] Thermal warning
[22] Ready,no thermal W
[23] Remote,ready,no TW
[24] Ready, Voltage OK
[25] Reverse
[26] Bus OK
[27] Torque limit & stop
[28] Brake, no brake war
102
Output is high when there is an active Start command (i.e. via digital input bus connection or [Hand
on] or [Auto on]), and no Stop or Start command is active.
Output is high when the frequency converter is running counter clockwise (the logical product of
the status bits 'running' AND 'reverse').
Output is high when the frequency converter is in Hand on mode (as indicated by the LED light
above [Hand on]).
Output is high when the frequency converter is in Hand on mode (as indicated by the LED light
above [Auto on]).
Function:
Digital Outputs
Functions are described under 5-3*
Function:
Digital Outputs
Functions are described under 5-3*
This parameter only applies to FC 302
Function:
This parameter is active when option module MCB 101 is mounted in the frequency converter.
Functions are described under 5-3* Digital Outputs
®
MG.33.M8.02 - VLT is a registered Danfoss trademark
FC 300 Programming Guide
