3 Parameter descriptions
6-16 Terminal 53 Filter Time Constant
Range:
0.001 s* [0.001 - 10.000 s]
3
3.8.4 6-2* Analog Input 2
Parameters for configuring the scaling and limits for analog input 2 (terminal 54).
6-20 Terminal 54 Low Voltage
Range:
0.07 V* [Application dependant]
6-21 Terminal 54 High Voltage
Range:
10.00 V* [Application dependant]
6-22 Terminal 54 Low Current
Range:
0.14 mA* [Application dependant]
6-23 Terminal 54 High Current
Range:
20.00 mA* [Application dependant]
6-24 Terminal 54 Low Ref./Feedb. Value
Range:
0 Referen- [-999999.999 - 999999.999 Refer-
ceFeedback- enceFeedbackUnit]
Unit*
6-25 Terminal 54 High Ref./Feedb. Value
Range:
Application [-999999.999 - 999999.999 Refer-
dependent* enceFeedbackUnit]
6-26 Terminal 54 Filter Time Constant
Range:
0.001 s* [0.001 - 10.000 s]
118
Function:
Enter the time constant. This is a first-order digital low pass filter time constant for suppressing
electrical noise in terminal 53. A high time constant value improves dampening but also increases
the time delay through the filter.
This parameter cannot be adjusted while the motor is running.
Function:
Enter the low voltage value. This analog input scaling value should correspond to the minimum
reference value, set in par. 3-02 Minimum Reference
Function:
Enter the high voltage value. This analog input scaling value should correspond to the high refer-
ence/feedback value set in par. 6-25
Function:
Enter the low current value. This reference signal should correspond to the minimum reference
value, set in par. 3-02 Minimum Reference
Live Zero Time-out Function in par. 6-01
Function:
Enter the high current value corresponding to the high reference/feedback value set in
Terminal 54 High Ref./Feedb. Value
par. 6-25
Function:
Enter the analog input scaling value that corresponds to the minimum reference feedback value set
Minimum Reference
in par. 3-02 .
Function:
Enter the analog input scaling value that corresponds to the maximum reference feedback value set
in par. 3-03 Maximum Reference .
Function:
Enter the time constant. This is a first-order digital low pass filter time constant for suppressing
electrical noise in terminal 54. A high time constant value improves dampening but also increases
the time delay through the filter.
This parameter cannot be adjusted while the motor is running.
®
MG.33.M8.02 - VLT is a registered Danfoss trademark
FC 300 Programming Guide
. See also the section
Terminal 54 High Ref./Feedb. Value .
. The value must be set at >2 mA in order to activate the
Live Zero Timeout Function .
.
Reference Handling .
