Danfoss VLT AutomationDrive FC 300 Programming Manual page 215

3 Parameter descriptions
16-21 Torque [%] High Res.
Range:
0.0 %* [-200.0 - 200.0 %]
16-22 Torque [%]
Range:
3
0 %* [-200 - 200 %]
16-25 Torque [Nm] High
Range:
0.0 Nm* [-200000000.0 - 200000000.0 Nm] View the torque value with sign, applied to the motor shaft. Some motors supply more than 160%
3.17.4 16-3* Drive Status
Parameters for reporting the status of the frequency converter.
16-30 DC Link Voltage
Range:
0 V* [0 - 10000 V]
16-32 Brake Energy /s
Range:
0.000 kW* [0.000 - 10000.000 kW]
16-33 Brake Energy /2 min
Range:
0.000 kW* [0.000 - 10000.000 kW]
16-34 Heatsink Temp.
Range:
0 C* [0 - 255 C]
16-35 Inverter Thermal
Range:
0 %* [0 - 100 %]
16-36 Inv. Nom. Current
Range:
Application [0.01 - 10000.00 A]
dependent*
16-37 Inv. Max. Current
Range:
Application [0.01 - 10000.00 A]
dependent*
214
Function:
The value shown is the torque in percent of nominal torque, with sign and 0.1% resolution, applied
to the motor shaft.
Function:
Value shown is the torque in percent of nominal torque, with sign, applied to the motor shaft.
Function:
torque. Consequently, the min. value and the max. value will depend on the max. motor current as
well as the motor used. This specific readout has been adapted to be able to show higher values
than the standard readout in par. 16-16
Function:
View a measured value. The value is filtered with an 30 ms time constant.
Function:
View the brake power transmitted to an external brake resistor, stated as an instantaneous value.
Function:
View the brake power transmitted to an external brake resistor. The mean power is calculated on
an average basis for the most recent 120 seconds.
Function:
View the frequency converter heatsink temperature. The cut-out limit is 90 ± 5 °C, and the motor
cuts back in at 60 ± 5 °C.
Function:
View the percentage load on the inverter.
Function:
View the inverter nominal current, which should match the nameplate data on the connected motor.
The data are used for calculation of torque, motor protection, etc.
Function:
View the inverter maximum current, which should match the nameplate data on the connected
motor. The data are used for calculation of torque, motor protection, etc.
®
MG.33.M8.02 - VLT is a registered Danfoss trademark
FC 300 Programming Guide
Torque [Nm] .
