FC 300 Programming Guide
4.1.6 5-** Digital In/Out
Par. Parameter description
No. #
5-0* Digital I/O mode
5-00 Digital I/O Mode
5-01 Terminal 27 Mode
5-02 Terminal 29 Mode
5-1* Digital Inputs
5-10 Terminal 18 Digital Input
5-11 Terminal 19 Digital Input
5-12 Terminal 27 Digital Input
5-13 Terminal 29 Digital Input
5-14 Terminal 32 Digital Input
5-15 Terminal 33 Digital Input
5-16 Terminal X30/2 Digital Input
5-17 Terminal X30/3 Digital Input
5-18 Terminal X30/4 Digital Input
5-19 Terminal 37 Safe Stop
5-20 Terminal X46/1 Digital Input
5-21 Terminal X46/3 Digital Input
5-22 Terminal X46/5 Digital Input
5-23 Terminal X46/7 Digital Input
5-24 Terminal X46/9 Digital Input
5-25 Terminal X46/11 Digital Input
5-26 Terminal X46/13 Digital Input
5-3* Digital Outputs
5-30 Terminal 27 Digital Output
5-31 Terminal 29 Digital Output
5-32 Term X30/6 Digi Out (MCB 101)
5-33 Term X30/7 Digi Out (MCB 101)
5-4* Relays
5-40 Function Relay
5-41 On Delay, Relay
5-42 Off Delay, Relay
5-5* Pulse Input
5-50 Term. 29 Low Frequency
5-51 Term. 29 High Frequency
5-52 Term. 29 Low Ref./Feedb. Value
5-53 Term. 29 High Ref./Feedb. Value
5-54 Pulse Filter Time Constant #29
5-55 Term. 33 Low Frequency
5-56 Term. 33 High Frequency
5-57 Term. 33 Low Ref./Feedb. Value
5-58 Term. 33 High Ref./Feedb. Value
5-59 Pulse Filter Time Constant #33
5-6* Pulse Output
5-60 Terminal 27 Pulse Output Variable
5-62 Pulse Output Max Freq #27
5-63 Terminal 29 Pulse Output Variable
5-65 Pulse Output Max Freq #29
5-66 Terminal X30/6 Pulse Output Variable
5-68 Pulse Output Max Freq #X30/6
5-7* 24V Encoder Input
5-70 Term 32/33 Pulses per Revolution
5-71 Term 32/33 Encoder Direction
5-9* Bus Controlled
5-90 Digital & Relay Bus Control
5-93 Pulse Out #27 Bus Control
5-94 Pulse Out #27 Timeout Preset
5-95 Pulse Out #29 Bus Control
5-96 Pulse Out #29 Timeout Preset
5-97 Pulse Out #X30/6 Bus Control
5-98 Pulse Out #X30/6 Timeout Preset
Default value
[0] PNP
[0] Input
[0] Input
null
null
null
null
null
null
null
null
null
[1] Safe Stop Alarm
[0] No operation
[0] No operation
[0] No operation
[0] No operation
[0] No operation
[0] No operation
[0] No operation
null
null
null
null
null
0.01 s
0.01 s
100 Hz
100 Hz
0.000 ReferenceFeedbackU-
nit
SR
100 ms
100 Hz
100 Hz
0.000 ReferenceFeedbackU-
nit
SR
100 ms
null
SR
null
SR
null
SR
1024 N/A
[0] Clockwise
0 N/A
0.00 %
0.00 %
0.00 %
0.00 %
0.00 %
0.00 %
®
MG.33.M8.02 - VLT is a registered Danfoss trademark
4-set-up FC 302 Change dur-
only ing opera-
tion
All set-ups FALSE
All set-ups TRUE
All set-ups x TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups x TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups x TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups x TRUE
All set-ups x TRUE
All set-ups x TRUE
All set-ups x TRUE
All set-ups x FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
All set-ups x TRUE
All set-ups x TRUE
All set-ups TRUE
All set-ups TRUE
All set-ups FALSE
All set-ups FALSE
All set-ups TRUE
All set-ups TRUE
1 set-up TRUE
All set-ups x TRUE
1 set-up x TRUE
All set-ups TRUE
1 set-up TRUE
4 Parameter Lists
Conver- Type
sion index
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
4
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
-2 Uint16
-2 Uint16
0 Uint32
0 Uint32
-3 Int32
-3 Int32
-3 Uint16
0 Uint32
0 Uint32
-3 Int32
-3 Int32
-3 Uint16
- Uint8
0 Uint32
- Uint8
0 Uint32
- Uint8
0 Uint32
0 Uint16
- Uint8
0 Uint32
-2 N2
-2 Uint16
-2 N2
-2 Uint16
-2 N2
-2 Uint16
239
