FC 300 Programming Guide
16-38 SL Controller State
Range:
0* [0 - 100 ]
16-39 Control Card Temp.
Range:
0 C* [0 - 100 C]
16-40 Logging Buffer Full
Option:
[0] * No
[1] Yes
16-49 Current Fault Source
Range:
0* [0 - 8 ]
3.17.5 16-5* Ref. & Feedb.
Parameters for reporting the reference and feedback input.
16-50 External Reference
Range:
0.0* [-200.0 - 200.0 ]
16-51 Pulse Reference
Range:
0.0* [-200.0 - 200.0 ]
16-52 Feedback [Unit]
Range:
0.000 Ref- [-999999.999 - 999999.999 Refer-
erenceFeed- enceFeedbackUnit]
backUnit*
16-53 Digi Pot Reference
Range:
0.00* [-200.00 - 200.00 ]
Function:
View the state of the event under execution by the SL controller.
Function:
View the temperature on the control card, stated in °C.
Function:
View whether the logging buffer is full (see parameter group 15-1*). The logging buffer will never
Logging Mode
be full when par. 15-13
Function:
Value indicates source of current faults including short circuit, over current, and phase imbalance
(from left):
1-4 Inverter
5-8 Rectifier
0 No fault recorded
Function:
View the total reference, the sum of digital, analog, preset, bus and freeze references, plus catch-
up and slow-down.
Function:
View the reference value from programmed digital input(s). The read-out can also reflect the im-
pulses from an incremental encoder.
Function:
View the feedback unit resulting from the selection of unit and scaling in par. 3-00
Range Reference/Feedback Unit
, par. 3-01
Reference
.
Function:
View the contribution of the Digital Potentiometer to the actual reference.
®
MG.33.M8.02 - VLT is a registered Danfoss trademark
3 Parameter descriptions
Log always
is set to [0].
Minimum Reference
, par. 3-02 and par. 3-03
3
Reference
Maximum
215
