3 Parameter descriptions
13-43 Logic Rule Operator 2
Array [6]
Option:
3
[0] * DISABLED
[1] AND
[2] OR
[3] AND NOT
[4] OR NOT
[5] NOT AND
[6] NOT OR
[7] NOT AND NOT
[8] NOT OR NOT
13-44 Logic Rule Boolean 3
Array [6]
Option:
[0] * False
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
188
Function:
Select the second logical operator to be used on the boolean input calculated in par. 13-40
Rule Boolean 1 , par. 13-41 Logic Rule Operator 1
boolean input coming from par. 13-42
[13-44] signifies the boolean input of par. 13-44
[13-40/13-42] signifies the boolean input calculated in par. 13-40
Logic Rule Operator 1
par. 13-41 , and par. 13-42
setting). select this option to ignore par. 13-44
Function:
Select the third boolean (TRUE or FALSE) input for the selected logic rule. See par. 13-01 ([0] -
[61]) and par. 13-02 ([70] - [75]) for further description.
®
MG.33.M8.02 - VLT is a registered Danfoss trademark
FC 300 Programming Guide
, and par. 13-42 Logic Rule Boolean 2
Logic Rule Boolean 2 .
Logic Rule Boolean 3
.
Logic Rule Boolean 1
Logic Rule Boolean 2
. DISABLED [0] (factory
Logic Rule Boolean 3
.
Logic
, and the
,
