FC 300 Programming Guide
17-56 Encoder Sim. Resolution
Set the resolution and activate the encoder emulation function (generation of encoder signals from the measured position from a resolver). Needed
when necessary to transfer the speed or position information from one drive to another. To disable the function, select [0].
Option:
[0] * Disabled
[1] 512
[2] 1024
[3] 2048
[4] 4096
17-59 Resolver Interface
Activate the MCB 103 resolver option when the resolver parameters are selected.
To avoid damage to resolvers par. 17-50
Option:
[0] * Disabled
[1] Enabled
3.18.5 17-6* Monitoring and Application
This parameter group is for selecting additional functions when MCB 102 Encoder option or MCB 103 Resolver option is fitted into option slot B as speed
feedback.
Monitoring and Application parameters cannot be adjusted while the motor is running.
17-60 Feedback Direction
Change the detected encoder rotation direction without changing the wiring to the encoder.
This parameter cannot be adjusted while the motor is running.
Option:
[0] * Clockwise
[1] Counter clockwise
17-61 Feedback Signal Monitoring
Select which reaction the frequency converter should take in case a faulty encoder signal is detected.
The encoder function in par. 17-61
Option:
[0] Disabled
[1] * Warning
[2] Trip
[3] Jog
[4] Freeze Output
[5] Max Speed
[6] Switch to Open Loop
[7] Select Setup 1
[8] Select Setup 2
[9] Select Setup 3
[10] Select Setup 4
[11] stop & trip
The value is stated in the data sheet for resolvers.
Function:
Poles Transformation Ratio
– par. 17-53
Function:
Function:
Feedback Signal Monitoring
is an electrical check of the hardware circuit in the encoder system.
Function:
®
MG.33.M8.02 - VLT is a registered Danfoss trademark
must be adjusted before activating this parameter.
3 Parameter descriptions
