Danfoss VLT AutomationDrive FC 300 Programming Manual page 192

FC 300 Programming Guide
[40] Drive stopped
[41] Reset Trip
[42] Auto-reset Trip
[43] Ok key
[44] Reset key
[45] Left key
[46] Right key
[47] Up key
[48] Down key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[75] Start command given
[76] Digital input x30 2
[77] Digital input x30 3
[78] Digital input x30 4
[79] Digital input x46 1
[80] Digital input x46 3
[81] Digital input x46 5
[82] Digital input x46 7
[83] Digital input x46 9
[84] Digital input x46 11
[85] Digital input x46 13
13-52 SL Controller Action
Array [20]
Option:
[0] * DISABLED
[1] No action
[2] Select set-up 1
[3] Select set-up 2
[4] Select set-up 3
[5] Select set-up 4
Function:
Select the action corresponding to the SLC event. Actions are executed when the corresponding
SL Controller Event
event (defined in par. 13-51
available for selection:
*DISABLED
[0]
No action [1]
Select set-up 1 [2] - changes the active set-up (par. 0-10) to '1'.
If the set-up is changed, it will merge with other set-up commands coming from either the digital
inputs or via a fieldbus.
Select set-up 2
[3] - changes the active set-up (par. 0-10) to '2'.
If the set-up is changed, it will merge with other set-up commands coming from either the digital
inputs or via a fieldbus.
Select set-up 3
[4] - changes the active set-up (par. 0-10) to '3'.
If the set-up is changed, it will merge with other set-up commands coming from either the digital
inputs or via a fieldbus.
Select set-up 4
[5] - changes the active set-up (par. 0-10) to '4'.
®
MG.33.M8.02 - VLT is a registered Danfoss trademark
3 Parameter descriptions
) is evaluated as true. The following actions are
3
191
