FC 300 Programming Guide
5-21 Terminal X46/3 Digital Input
Option:
[0] * No operation
5-22 Terminal X46/5 Digital Input
Option:
[0] * No operation
5-23 Terminal X46/7 Digital Input
Option:
[0] * No operation
5-24 Terminal X46/9 Digital Input
Option:
[0] * No operation
5-25 Terminal X46/11 Digital Input
Option:
[0] * No operation
5-26 Terminal X46/13 Digital Input
Option:
[0] * No operation
3.7.4 5-3* Digital Outputs
Parameters for configuring the output functions for the output terminals. The 2 solid-state digital outputs are common for terminals 27 and 29. Set the
I/O function for terminal 27 in par. 5-01
cannot be adjusted while the motor is running.
[0] No operation
[1] Control ready
[2] Drive ready
[3] Drive ready / remote control
[4] Enable / no warning
[5] VLT running
[6] Running / no warning
[7] Run in range / no warning
[8] Run on reference / no warning
[9] Alarm
[10] Alarm or warning
[11] At torque limit
[12] Out of current range
Function:
This parameter is active when option moduleMCB 113 is installed in the frequency converter. Func-
tions are described under 5-1*
Function:
This parameter is active when option moduleMCB 113 is installed in the frequency converter. Func-
tions are described under 5-1*
Function:
This parameter is active when option moduleMCB 113 is installed in the frequency converter. Func-
tions are described under 5-1*
Function:
This parameter is active when option module MCB 113 is installed in the frequency converter. Func-
tions are described under 5-1*
Function:
This parameter is active when option moduleMCB 113 is installed in the frequency converter. Func-
tions are described under 5-1*
Function:
This parameter is active when option module MCB 113 is installed in the frequency converter. Func-
tions are described under 5-1*
Terminal 27 Mode , and set the I/O function for terminal 29 in par. 5-02
Default for all digital outputs and relay outputs
The control card is ready. E.g.: Feedback from a drive where the control is supplied by an external
24 V (MCB107) and the main power to drive is not detected.
The frequency converter is ready for operation and applies a supply signal on the control board.
The frequency converter is ready for operation and is in Auto On mode.
Ready for operation. No start or stop command is been given (start/disable). No warnings are active.
Motor is running and shaft torque present.
Output speed is higher than the speed set in par. 1-81
motor is running and there are no warnings.
Motor is running within the programmed current and speed ranges set in par. 4-50
Low Warning Speed High
to par. 4-53
Motor runs at reference speed. No warnings.
An alarm activates the output. There are no warnings.
An alarm or a warning activates the output.
The torque limit set in par. 4-16
The motor current is outside the range set in par. 4-18
®
MG.33.M8.02 - VLT is a registered Danfoss trademark
Digital Inputs
Digital Inputs
Digital Inputs
Digital Inputs
Digital Inputs
Digital Inputs
Terminal 29 Mode
Min Speed for Function at Stop [RPM]
. There are no warnings.
Torque Limit Motor Mode
or par. 4-17 has been exceeded.
Current Limit
3 Parameter descriptions
. These parameters
. The
Warning Current
.
99
3
