Danfoss VLT AutomationDrive FC 300 Programming Manual page 178

FC 300 Programming Guide
[5] Torque limit
[6] Current limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
[27] Logic rule 1
[28] Logic rule 2
[29] Logic rule 3
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[39] Start command
[40] Drive stopped
Torque limit
[5] The torque limit, set in par. 4-16
Limit Generator Mode , has been exceeded.
Current limit
[6] The motor current limit, set in par. 4-18
Out of current range
[7] The motor current is outside the range set in par. 4-18
Below I low
[8] The motor current is lower than set in par. 4-50
Above I high [9] The motor current is higher than set in par. 4-51
Out of speed range
[10] The speed is outside the range set in par. 4-52
Warning Speed High
par. 4-53 .
Below speed low
[11] The output speed is lower than the setting in par. 4-52
Above speed high [12] The output speed is higher than the setting in par. 4-53
High .
Out of feedb. Range
[13] The feedback is outside the range set in par. 4-56
Low Warning Feedback High
and par. 4-57
Below feedb. Low [14] The feedback is below the limit set in par. 4-56
Above feedb. High [15] The feedback is above the limit set in par. 4-57
Thermal warning
[16] The thermal warning turns on when the temperature exceeds the limit in the
motor, the frequency converter, the brake resistor or the thermistor.
Mains out of range
[17] The mains voltage is outside the specified voltage range.
Reversing [18] The output is high when the frequency converter is running counter clockwise (the
logical product of the status bits "running" AND "reverse").
Warning
[19] A warning is active.
Alarm (trip)
[20] A (trip) alarm is active.
Alarm (trip lock) [21] A (Trip lock) alarm is active.
Comparator 0
[22] Use the result of comparator 0.
Comparator 1
[23] Use the result of comparator 1.
Comparator 2
[24] Use the result of comparator 2.
Comparator 3 [25] Use the result of comparator 3.
Logic rule 0
[26] Use the result of logic rule 0.
Logic rule 1
[27] Use the result of logic rule 1.
Logic rule 2
[28] Use the result of logic rule 2.
Logic rule 3 [29] Use the result of logic rule 3.
Digital input DI18
[33] Use the result of digital input 18.
Digital input DI19
[34] Use the result of digital input 19.
Digital input DI27 [35] Use the result of digital input 27.
Digital input DI27 [35] Use the result of digital input 29.
Digital input DI32
[37] Use the result of digital input 32.
Digital input DI33
[38] Use the result of digital input 33.
Start command [39] A start command is issued.
Drive stopped [40] A stop command ( Jog, Stop, Qstop, Coast) is issued – and not from the SLC
itself.
®
MG.33.M8.02 - VLT is a registered Danfoss trademark
3 Parameter descriptions
Torque Limit Motor Mode
or par. 4-17
Current Limit
, has been exceeded.
Warning Current Low
Warning Current High
Warning Speed Low
Warning Speed Low
.
Warning Feedback Low
Warning Feedback High
Torque
Current Limit
.
.
.
3
and
.
Warning Speed
Warning Feedback
.
.
177
