Danfoss VLT AutomationDrive FC 300 Programming Manual page 223

3 Parameter descriptions
17-25 Clock Rate
Range:
Application [Application dependant]
dependent*
17-26 SSI Data Format
Option:
3
[0] * Gray code
[1] Binary code
17-34 HIPERFACE Baudrate
Select the baud rate of the attached encoder.
This parameter cannot be adjusted while the motor is running. The parameter is only accessible when par. 17-20
[1].
Option:
[0] 600
[1] 1200
[2] 2400
[3] 4800
[4] * 9600
[5] 19200
[6] 38400
3.18.4 17-5* Resolver Interface
Parameter group 17-5* is used for setting parameters for the MCB 103 Resolver Option.
Usually the resolver feedback is used as motor feedback from Permanent Magnet motors with par. 1-01
feedback.
Resolver parameters cannot be adjusted while the motor is running.
17-50 Poles
Range:
2* [2 - 2 ]
17-51 Input Voltage
Range:
7.0 V* [2.0 - 8.0 V]
17-52 Input Frequency
Range:
10.0 kHz* [2.0 - 15.0 kHz]
17-53 Transformation Ratio
Range:
0.5* [0.1 - 1.1 ]
222
Function:
Set the SSI clock rate. With long encoder cables the clock rate must be reduced.
Function:
Set the data format of the SSI data. Choose between Gray or Binary format.
Function:
Function:
Set the number of poles on the resolver.
The value is stated in the data sheet for resolvers.
Function:
Set the input voltage to the resolver. The voltage is stated as RMS value.
The value is stated in the data sheet for resolvers
Function:
Set the input frequency to the resolver.
The value is stated in the data sheet for resolvers.
Function:
Set the transformation ratio for the resolver.
The transformation ration is:
V Out
T ratio =
V In
®
MG.33.M8.02 - VLT is a registered Danfoss trademark
FC 300 Programming Guide
Protocol Selection is set to HIPERFACE
Motor Control Principle
set to Flux with motor
