Danfoss VLT AutomationDrive FC 300 Programming Manual page 91

3 Parameter descriptions
4-50 Warning Current Low
Range:
0.00 A* [Application dependant]
4-51 Warning Current High
3
Range:
Application [Application dependant]
dependent*
4-52 Warning Speed Low
Range:
0 RPM* [Application dependant]
4-53 Warning Speed High
Range:
Application [Application dependant]
dependent*
4-54 Warning Reference Low
Range:
-999999.99 [Application dependant]
9*
4-55 Warning Reference High
Range:
999999.999 [Application dependant]
*
4-56 Warning Feedback Low
Range:
-999999.99 [Application dependant]
9 Referen-
ceFeedback-
Unit*
4-57 Warning Feedback High
Range:
999999.999 [Application dependant]
Reference-
FeedbackU-
nit*
90
Function:
Enter the I value. When the motor current falls below this limit, the display reads
LOW
The signal outputs can be programmed to produce a status signal on terminal 27 or 29 (FC 302
only) and on relay output 01 or 02 (FC 302 only). Refer to the drawing in this section.
Function:
Enter the I value. When the motor current exceeds this limit, the display reads
HIGH
The signal outputs can be programmed to produce a status signal on terminal 27 or 29 (FC 302
only) and on relay output 01 or 02 (FC 302 only). Refer to the drawing in this section.
Function:
Enter the n value. When the motor speed exceeds this limit, the display reads
LOW
signal outputs can be programmed to produce a status signal on terminal 27 or 29 (FC 302 only)
and on relay output 01 or 02 (FC 302 only).
Function:
Enter the n value. When the motor speed exceeds this limit, the display reads
HIGH
signal outputs can be programmed to produce a status signal on terminal 27 or 29 (FC 302 only)
and on relay output 01 or 02 (FC 302 only). Programme the upper signal limit of the motor speed,
n , within the normal working range of the frequency converter. Refer to the drawing in this
HIGH
section.
Function:
Enter the lower reference limit. When the actual reference falls below this limit, the display indicates
Ref Low
. The signal outputs can be programmed to produce a status signal on terminal 27 or 29
(FC 302 only) and on relay output 01 or 02 (FC 302 only).
Function:
Enter the upper reference limit. When the actual reference exceeds this limit, the display reads Ref
High. The signal outputs can be programmed to produce a status signal on terminal 27 or 29 (FC
302 only) and on relay output 01 or 02 (FC 302 only).
Function:
Enter the lower feedback limit. When the feedback falls below this limit, the display reads Feedb
Low. The signal outputs can be programmed to produce a status signal on terminal 27 or 29 (FC
302 only) and on relay output 01 or 02 (FC 302 only).
Function:
Enter the upper feedback limit. When the feedback exceeds this limit, the display reads Feedb High.
The signal outputs can be programmed to produce a status signal on terminal 27 or 29 (FC 302
only) and on relay output 01 or 02 (FC 302 only).
®
MG.33.M8.02 - VLT is a registered Danfoss trademark
FC 300 Programming Guide
Current Low
.
Current High
.
Speed Low
. The
Speed High . The
