Parameter Descriptions

4.11 Parameters: 12-** Ethernet

4.11.1 12-0* IP Settings
12-00 IP Address Assignment
Option:
4 4
[0] MANUAL
[1] DHCP
[2] BOOTP
[10] DCP
*
[20] From node ID
12-01 IP Address
Range:
0
*
4294967295 ]
12-02 Subnet Mask
Range:
0 [0 -
*
4294967295]
12-03 Default Gateway
Range:
0
*
2147483647 ]
12-04 DHCP Server
Range:
0
*
2147483647 ]
112
Function:
Select the IP address assignment
method.
IP address can be set in
parameter 12-01 IP Address IP
Address.
IP address is assigned via DHCP
server.
IP address is assigned via BOOTP
server.
DCP is assigned via the DCP
protocol.
Function:
[0 - Configure the IP address of the
option. Read-only, if
parameter 12-00 IP Address
Assignment is set to DHCP or
BOOTP. In POWERLINK, the IP
address follows the
parameter 12-60 Node ID last byte
and the first part is fixed to
192.168.100 (node ID).
Function:
Configure the IP subnet mask of the
option. Read-only, if parameter 12-00 IP
Address Assignment is set to DHCP or
BOOTP. In POWERLINK, it is fixed to
255.255.255.0.
Function:
[0 - Configure the IP default gateway of
the option. Read-only, if
parameter 12-00 IP Address
Assignment is set to DHCP or
BOOTP. In a non-routed network,
this address is set to the IP address
of the IO Device.
Function:
[0 - Read-only. Show the IP address of
the found DHCP or BOOTP server.
Danfoss A/S © 03/2019 All rights reserved.
VLT® AutomationDrive FC 361
12-05 Lease Expires
Range:
Size
related
*
12-06 Name Servers
Range:
0
*
12-07 Domain Name
Range:
0
12-08 Host Name
Range:
0
*
12-09 Physical Address
Range:
0
*
4.11.2 12-1* Ethernet Link Parameters
Apply to the whole parameter group.
Index [0] is used for port 1, and index [1] is used for port
2.
12-10 Link Status
Read-only. Shows the link status of the Ethernet ports.
Option:
[0]
*
[1]
Function:
[ 0 - 0 ] Read-only. Show the lease time left
for the current DHCP-assigned IP
address.
Function:
[0 - IP addresses of domain name
2147483647 ] servers. Can be automatically
assigned when using DHCP.
Function:
[0 - 48 ] Domain name of the attached
network. Can be automatically
assigned when using DHCP
network.
Function:
[0 - 48 ] Logical (given) name of option.
NOTICE
The display of the frequency
converter only shows the first
19 characters, but the
remaining characters are
stored in the frequency
converter. If hardware switches
are different from all ON or all
OFF, the switches have priority.
Function:
[0 - 17 ] Read-only. Show the physical (MAC)
address of the option.
Function:
No Link
Link
