FC 300 Programming Guide
[3] Trip after stop
4-35 Tracking Error
Range:
10 RPM* [1 - 600 RPM]
4-36 Tracking Error Timeout
Range:
1.00 s* [0.00 - 60.00 s]
4-37 Tracking Error Ramping
Range:
100 RPM* [1 - 600 RPM]
4-38 Tracking Error Ramping Timeout
Range:
1.00 s* [0.00 - 60.00 s]
4-39 Tracking Error After Ramping Timeout
Range:
5.00 s* [0.00 - 60.00 s]
3.6.4 4-5* Adjustable Warnings
This is where adjustable warning limits for current, speed, reference and feedback can be defined. Warnings that are shown on the display can be
programmed as an output or sent via serial bus.
Warnings are shown on display, programmed output or serial bus.
Function:
Enter the maximum permissible speed error between the motor speed and the output of the ramp
when not ramping. In open loop the motor speed is estimated and in closed loop it is the feedback
from encoder/resolver.
Function:
Enter the time-out period during which an error greater than the value set in par. 4-35
Error is permissible.
Function:
Enter the maximum permissible speed error between the motor speed and the output of the ramp
when ramping. In open loop the motor speed is estimated and in closed loop it is the feedback from
encoder/resolver.
Function:
Enter the time-out period during which an error greater than the value set in par. 4-37
Error Ramping
while Ramping is permissible.
Function:
Enter the time-out period after ramping where par. 4-37
Tracking Error Ramping Timeout
par. 4-38
®
MG.33.M8.02 - VLT is a registered Danfoss trademark
3 Parameter descriptions
Tracking Error Ramping
are still active.
3
Tracking
Tracking
and
