3 Parameter descriptions
[1625] Torque [Nm] High
[1630] DC Link Voltage
[1632] Brake Energy /s
[1633] Brake Energy /2 min
3
[1634] Heatsink Temp.
[1635] Inverter Thermal
[1636] Inv. Nom. Current
[1637] Inv. Max. Current
[1638] SL Controller State
[1639] Control Card Temp.
[1650] External Reference
[1651] Pulse Reference
[1652] Feedback [Unit]
[1653] Digi Pot Reference
[1660] Digital Input
[1661] Terminal 53 Switch Setting
[1662] Analog Input 53
[1663] Terminal 54 Switch Setting
[1664] Analog Input 54
[1665] Analog Output 42 [mA]
[1666] Digital Output [bin]
[1667] Freq. Input #29 [Hz]
[1668] Freq. Input #33 [Hz]
[1669] Pulse Output #27 [Hz]
[1670] Pulse Output #29 [Hz]
[1671] Relay Output [bin]
[1672] Counter A
[1673] Counter B
[1674] Prec. Stop Counter
[1675] Analog In X30/11
[1676] Analog In X30/12
[1677] Analog Out X30/8 [mA]
[1678] Analog Out X45/1 [mA]
[1679] Analog Out X45/3 [mA]
[1680] Fieldbus CTW 1
36
Intermediate circuit voltage in the frequency converter.
Present brake power transferred to an external brake resistor.
Stated as an instantaneous value.
Brake power transferred to an external brake resistor. The mean power is calculated continuously
for the most recent 120 seconds.
Present heat sink temperature of the frequency converter. The cut-out limit is 95 ±5 oC; cutting
back in occurs at 70 ±5° C.
Percentage load of the inverters.
Nominal current of the frequency converter.
Maximum current of the frequency converter.
State of the event executed by the control.
Temperature of the control card.
Sum of the external reference as a percentage, i.e. the sum of analog/pulse/bus.
Frequency in Hz connected to the digital inputs (18, 19 or 32, 33).
Reference value from programmed digital input(s).
Signal states form the 6 digital terminals (18, 19, 27, 29, 32 and 33). There are 16 bits in total, but
only six of them are used. Input 18 corresponds to the leftmost of the used bits. Signal low = 0;
Signal high = 1.
Setting of input terminal 54. Current = 0; Voltage = 1.
Actual value at input 53 either as a reference or protection value.
Setting of input terminal 54. Current = 0; Voltage = 1.
Actual value at input 54 either as reference or protection value.
Actual value at output 42 in mA. Use par. 6-50
Binary value of all digital outputs.
Actual value of the frequency applied at terminal 29 as an impulse input.
Actual value of the frequency applied at terminal 33 as an impulse input.
Actual value of impulses applied to terminal 27 in digital output mode.
Actual value of impulses applied to terminal 29 in digital output mode.
Application dependent (e.g. SLC Control)
Application dependent (e.g. SLC Control)
Display the actual counter value.
Actual value at input X30/11 either as reference or protection value.
Actual value at input X30/12 either as reference or protection value.
Actual value at output X30/8 in mA. Use par. 6-60
shown.
Control word (CTW) received from the Bus Master.
®
