3 Parameter descriptions
[29] Logic rule 3
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
3
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
15-13 Logging Mode
Option:
[0] * Log always
[1] Log once on trigger
15-14 Samples Before Trigger
Range:
50* [0 - 100 ]
3.16.4 15-2* Historic Log
View up to 50 logged data items via the array parameters in this parameter group. For all parameters in the group, [0] is the most recent data and [49]
the oldest data. Data is logged every time an
of the following areas:
1. Digital input
2. Digital outputs (not monitored in this SW release)
3. Warning word
4. Alarm word
5. Status word
6. Control word
7. Extended status word
Events are logged with value, and time stamp in msec. The time interval between two events depends on how often
scan time). Data logging is continuous but if an alarm occurs, the log is saved and the values can be viewed on the display. This feature is useful, for
example when carrying out service following a trip. View the historic log contained in this parameter via the serial communication port or via the display.
15-20 Historic Log: Event
Array [50]
Range:
0 N/A* [0 - 255 N/A]
15-21 Historic Log: Value
Array [50]
Range:
0 N/A* [0 - 2147483647 N/A]
208
Function:
Log always
Select [0] for continuous logging.
Select Log once on trigger [1] to conditionally start and stop logging using par. 15-12
Event and par. 15-14 Samples Before Trigger
Function:
Enter the percentage of all samples prior to a trigger event which are to be retained in the log. See
also par. 15-12 Trigger Event and par. 15-13
event occurs (not to be confused with SLC events).
Function:
View the event type of the logged events.
Function:
View the value of the logged event. Interpret the event values according to this table:
®
MG.33.M8.02 - VLT is a registered Danfoss trademark
FC 300 Programming Guide
.
Logging Mode .
Events in this context are defined as a change in one
events occur (maximum once every
Trigger
