Danfoss VLT AutomationDrive FC 300 Programming Manual page 183

3 Parameter descriptions
[101] Comparator 1
[102] Comparator 2
[103] Comparator 3
[104] Comparator 4
[105] Comparator 5
3
[110] Logic rule 0
[111] Logic rule 1
[112] Logic rule 2
[113] Logic rule 3
[114] Logic rule 4
[115] Logic rule 5
[120] SL Time-out 0
[121] SL Time-out 1
[122] SL Time-out 2
[123] SL Time-out 3
[124] SL Time-out 4
[125] SL Time-out 5
[126] SL Time-out 6
[127] SL Time-out 7
[130] Digital input DI18
[131] Digital input DI19
[132] Digital input DI27
[133] Digital input DI29
[134] Digital input DI32
[135] Digital input DI33
[150] SL digital output A
[151] SL digital output B
[152] SL digital output C
[153] SL digital output D
[154] SL digital output E
[155] SL digital output F
[160] Relay 1
[161] Relay 2
[180] Local ref. active
[181] Remote ref. active
[182] Start command
182
Comparator 1
[101] The result of comparator 1.
Comparator 2 [102] The result of comparator 2.
Comparator 3
[103] The result of comparator 3.
Comparator 4
[104] The result of comparator 4.
Comparator 5 [105] The result of comparator 5.
Logic rule 0 [110] The result of Logic rule 0.
Logic rule 1
[111] The result of Logic rule 1.
Logic rule 2
[112] The result of Logic rule 2.
Logic rule 3 [113] The result of Logic rule 3.
Logic rule 4
[114] The result of Logic rule 4.
Logic rule 5
[115] The result of Logic rule 5.
SL Time-out 0
[120] The result of SLC timer 0.
SL Time-out 1 [121] The result of SLC timer 1.
SL Time-out 2
[122] The result of SLC timer 2.
SL Time-out 3
[123] The result of SLC timer 3.
SL Time-out 4
[124] The result of SLC timer 4.
SL Time-out 5 [125] The result of SLC timer 5.
SL Time-out 6
[126] The result of SLC timer 6.
SL Time-out 7
[127] The result of SLC timer 7.
Digital input DI18
[130] Digital input 18. High = True.
Digital input DI19 [131] Digital input 19. High = True.
Digital input DI27
[132] Digital input 27. High = True.
Digital input DI29
[133] Digital input 29. High = True.
Digital input DI32 [134] Digital input 32. High = True.
Digital input DI33 [135] Digital input 33. High = True.
SL digital output A
[150] Use the result of the SLC output A.
SL digital output B
[151] Use the result of the SLC output B.
SL digital output C [152] Use the result of the SLC output C.
SL digital output D
[153] Use the result of the SLC output D.
SL digital output E
[154] Use the result of the SLC output E.
SL digital output F
[155] Use the result of the SLC output F.
Relay 1 [160] Relay 1 is active
Relay 2
[161] Relay 2 is active
Local ref. active
[180] High when par. 3-13
Site
is [0] Linked to hand Auto, at the same time as the LCP is in Hand on mode.
Remote ref. active [181] High when par. 3-13
auto, while the LCP is in Auto on mode.
Start command
[182] High when there is an active start command, and no stop command.
®
MG.33.M8.02 - VLT is a registered Danfoss trademark
FC 300 Programming Guide
Reference Site
= [2] Local or when par. 3-13
Reference Site = [1] Remote or [0] Linked to hand/
Reference
