3 Parameter descriptions
[4] Quick stop inverse
[5] DC-brake inverse
[6] Stop inverse
3
[8] Start
[9] Latched start
[10] Reversing
[11] Start reversing
[12] Enable start forward
[13] Enable start reverse
[14] Jog
[15] Preset reference on
[16] Preset ref bit 0
[17] Preset ref bit 1
[18] Preset ref bit 2
Preset ref. bit
Preset ref. 0
Preset ref. 1
Preset ref. 2
Preset ref. 3
Preset ref. 4
Preset ref. 5
Preset ref. 6
Preset ref. 7
[19] Freeze ref
[20] Freeze output
94
Inverted input (NC). Generates a stop in accordance with quick-stop ramp time set in par. 3-81
Stop Ramp Time . When motor stops, the shaft is in free mode. Logic '0' => Quick-stop.
Inverted input for DC braking (NC). Stops motor by energizing it with a DC current for a certain time
period. See par. 2-01 DC Brake Current
only active when the value in par. 2-02
Stop Inverted function. Generates a stop function when the selected terminal goes from logical level
'1' to '0'. The stop is performed according to the selected ramp time (par. 3-42
Time , par. 3-52 Ramp 2 Ramp down Time
Ramp Down Time ).
NB!
When the frequency converter is at the torque limit and has received a stop
command, it may not stop by itself. To ensure that the frequency converter stops,
configure a digital output to
output to a digital input that is configured as coast.
(Default Digital input 18): Select start for a start/stop command. Logic '1' = start, logic '0' = stop.
The motor starts, if a pulse is applied for min. 2 ms. The motor stops when Stop inverse is activated.
(Default Digital input 19). Change the direction of motor shaft rotation. Select Logic '1' to reverse.
The reversing signal only changes the direction of rotation. It does not activate the start function.
Select both directions in par. 4-10 Motor Speed Direction
loop.
Used for start/stop and for reversing on the same wire. Signals on start are not allowed at the same
time.
Disengages the counterclockwise movement and allows for the clockwise direction.
Disengages the clockwise movement and allows for the counterclockwise direction.
(Default Digital input 29): Use to activate jog speed. See par. 3-11
Shifts between external reference and preset reference. It is assumed that
been selected in par. 3-04 Reference Function
of the eight preset references is active.
Preset ref. bit 0,1, and 2 enables a choice between one of the eight preset references according to
the table below.
Same as Preset ref bit 0 [16].
Same as Preset ref bit 0 [16].
2
0
0
0
0
1
1
1
1
Freezes the actual reference, which is now the point of enable/condition for Speed up and Speed
down to be used. If Speed up/down is used, the speed change always follows ramp 2
Ramp 2 Ramp up Time
(par. 3-51
Maximum Reference
par. 3-03 .
Freezes the actual motor frequency (Hz), which is now the point of enable/condition for Speed up
and Speed down to be used. If Speed up/down is used, the speed change always follows ramp 2
Ramp 2 Ramp up Time
(par. 3-51
Motor Frequency
par. 1-23 .
®
MG.33.M8.02 - VLT is a registered Danfoss trademark
FC 300 Programming Guide
to par. 2-03 DC Brake Cut In Speed [RPM]
DC Braking Time is different from 0. Logic '0' => DC braking.
, par. 3-62 Ramp 3 Ramp down Time
Torque limit & stop
[27] and connect this digital
. The function is not active in process closed
Jog Speed [Hz]
. Logic '0' = external reference active; logic '1' = one
1
0
0
1
1
0
0
1
1
Ramp 2 Ramp down Time
and par. 3-52
Ramp 2 Ramp down Time
and par. 3-52
Quick
. The function is
Ramp 1 Ramp Down
, par. 3-72 Ramp 4
.
External/preset
[1] has
0
0
1
0
1
0
1
0
1
) in the range 0 -
) in the range 0 -
