3 Parameter descriptions
[103] Motor current
[104] Torque rel to limit
[105] Torq relate to rated
[106] Power
[107] Speed
[108] Torque
[109] Max Out Freq
3
[119] Torque % lim
5-62 Pulse Output Max Freq #27
Range:
Application [0 - 32000 Hz]
dependent*
5-63 Terminal 29 Pulse Output Variable
Option:
[0] * No operation
[45] Bus ctrl.
[48] Bus ctrl., timeout
[51] MCO controlled
[100] Output frequency
[101] Reference
[102] Feedback
[103] Motor current
[104] Torque rel to limit
[105] Torq relate to rated
[106] Power
[107] Speed
[108] Torque
[109] Max Out Freq
[119] Torque % lim
5-65 Pulse Output Max Freq #29
Set the maximum frequency for terminal 29 corresponding to the output variable set in par. 5-63
This parameter cannot be adjusted while the motor is running.
Range:
5000 Hz* [0 - 32000 Hz]
5-66 Terminal X30/6 Pulse Output Variable
Select the variable for read-out on terminal X30/6.
This parameter cannot be adjusted while the motor is running.
This parameter is active when option module MCB 101 is installed in the frequency converter.
Same options and functions as par. group 5-6*.
Option:
[0] * No operation
[45] Bus ctrl.
[48] Bus ctrl., timeout
[51] MCO controlled
112
Function:
Set the maximum frequency for terminal 27, corresponding to the output variable selected in
par. 5-60 Terminal 27 Pulse Output Variable
This parameter cannot be adjusted while the motor is running.
Function:
Select the desired display output for terminal 29. This parameter is available for FC 302 only.
This parameter cannot be adjusted while the motor is running.
Function:
Function:
®
MG.33.M8.02 - VLT is a registered Danfoss trademark
FC 300 Programming Guide
.
Terminal 29 Pulse Output Variable .
