[0] * Disable
[1] Trigger on alarms
[2] Trigger alarm/warn.
8-08 Readout Filtering
The function is used if the speed feedback value readouts on fieldbus are fluctuating. Select filtered if the function is required. A power-cycle is required
for changes to take effect.
Option:
[0] * Motor Data Std-Filt.
[1] Motor Data LP-Filter
3.10.3 8-1* Ctrl. Word Settings
Parameters for configuring the option control word profile.
8-10 Control Word Profile
Select the interpretation of the control and status words corresponding to the installed fieldbus. Only the selections valid for the fieldbus installed in
slot A will be visible in the LCP display.
FC profile
For guidelines in selection of
NB!
This is only valid for Profibus.
Disable
- [0]: Do not send extended diagnosis data even if they appear in the frequency
converter.
Trigger on alarms
-
alarm par. 16-90
Trigger alarms/warn.
-
appear in alarm par. 16-90
Warning Word
par. 16-92
The content of the extended diagnosis frame is as follows:
Byte Content
0 - 5 Standard DP Diagnose Data Standard DP Diagnose Data
6 PDU length xx
7 Status type = 0x81
8 Slot = 0
9 Status info = 0
10 - 13 VLT par. 16-92
Word
14 - 17 VLT par. 16-03
18 - 21 VLT par. 16-90
22 - 23 VLT par. 9-53
Warning Word
Enabling diagnosis may cause increased bus traffic. Diagnosis functions are not supported by all
fieldbus types.
Function:
Select [0] for normal bus readouts.
Select [1] for filtered bus readouts of the following parameters:
Power [kW]
Par. 16-10
Power [hp]
Par. 16-11
Motor Voltage
Par. 16-12
Motor Current
Par. 16-14
Par. 16-16 Torque [Nm]
Par. 16-17 Speed [RPM]
Par. 16-22 Torque [%]
Torque [Nm] High
Par. 16-25
PROFIdrive profile
[0] and [1] please refer to the
®
MG.33.M8.02 - VLT is a registered Danfoss trademark
[1]: Send extended diagnosis data when one or more alarms appear in
Alarm Word Profibus Warning Word
or par. 9-53
[2]: Send extended diagnosis data if one or more alarms or warnings
Alarm Word Profibus Warning Word
, par. 9-53
.
Description
Header of extended diagnostic data
Header of extended diagnostic data
Header of extended diagnostic data
Header of extended diagnostic data
Warning
VLT warning word
Status Word
VLT status word
Alarm Word VLT alarm word
Profibus
Communication warning word (Profibus)
Serial communication via RS 485 Interface
3 Parameter descriptions
3
.
, or warning
section.
