3 Parameter descriptions
The active setup (i.e. the setup in which the frequency converter is currently operating) can be selected in par. 0-10
the LCP. Using Multi set-up it is possible to switch between setups with the frequency converter running or stopped, via digital input or serial communication
commands. If it is necessary to change setups whilst running, ensure par. 0-12
Set-up it is possible to edit parameters within any of the setups whilst continuing the frequency converter operation in its Active Setup which can be a
different setup to that being edited. Using par. 0-51
missioning if similar parameter settings are required in different setups.
0-10 Active Set-up
Option:
3
[0] Factory setup
[1] * Set-up 1
[2] Set-up 2
[3] Set-up 3
[4] Set-up 4
[9] Multi Set-up
Use par. 0-51 Set-up Copy
marked 'not changeable during operation' have different values. To avoid conflicting settings of the same parameter within two different set-ups, link the
set-ups together using par. 0-12
Parameter Lists
in the section
0-11 Edit Set-up
Option:
[0] Factory setup
[1] * Set-up 1
[2] Set-up 2
[3] Set-up 3
[4] Set-up 4
[9] Active Set-up
32
Set-up Copy
Function:
Select the set-up to control the frequency converter functions.
Cannot be changed. It contains the Danfoss data set, and can be used as a data source when
returning the other set-ups to a known state.
Set-up 1
[1] to
can be programmed.
Remote selection of set-ups using digital inputs and the serial communication port. This set-up uses
the settings from par. 0-12
changes to open- and closed loop functions
to copy a set-up to one or all other set-ups. Stop the frequency converter before switching between set-ups where parameters
This Set-up Linked to
. Parameters which are 'not changeable during operation' are marked FALSE in the parameter lists
.
Function:
Select the set-up to be edited (i.e. programmed) during operation; either the active set-up or one
of the inactive set-ups.
Cannot be edited but it is useful as a data source to return the other set-ups to a known state.
Set-up 1
[1] to
up.
Can also be edited during operation. Edit the chosen set-up from a range of sources: LCP, FC RS485,
FC USB or up to five fieldbus sites.
MG.33.M8.02 - VLT
This Set-up Linked to is programmed as required. Using par. 0-11
it is possible to copy parameter settings between the setups to enable quicker com-
Set-up 4
[4] are the four separate parameter set-ups within which all parameters
This Set-up Linked to
Set-up 4
[4] can be edited freely during operation, independently of the active set-
®
is a registered Danfoss trademark
FC 300 Programming Guide
Active Set-up
and is displayed in
. Stop the frequency converter before making
Edit
