Parameter Lists
VLT

5.1.13 8-** Comm. and Options

Parameter
Parameter Description
Number
8-01 Control Site
8-02 Control Word Source
8-03 Control Word Timeout Time
8-04 Control Word Timeout Function
8-06 Reset Control Word Timeout
8-30 Protocol
8-31 Address
5 5
8-32 FC Port Baud Rate
8-33 FC Port Parity
8-35 Minimum Response Delay
8-36 Max Response Delay
8-43 FC Port PCD Read Configuration
8-50 Coasting Select
8-51 Quick Stop Select
8-52 DC Brake Select
8-53 Start Select
8-54 Reversing Select
8-55 Set-up Select
8-56 Preset Reference Select
8-94 Bus feedback 1
Table 5.16

5.1.14 13-** Smart Logic

Parameter
Parameter Description
Number
13-00 SL Controller Mode
13-01 Start Event
13-02 Stop Event
13-03 Reset SLC
13-10 Comparator Operand
13-11 Comparator Operator
13-12 Comparator Value
13-20 SL Controller Timer
13-40 Logic Rule Boolean 1
13-41 Logic Rule Operator 1
13-42 Logic Rule Boolean 2
13-43 Logic Rule Operator 2
13-44 Logic Rule Boolean 3
13-51 SL Controller Event
13-52 SL Controller Action
Table 5.17
60 MG02C602 - VLT
RSPSupply - 1-888-532-2706 - www.RSPSupply.com
http://www.RSPSupply.com/p-12769-Danfoss-132F0026-VFD-Micro-Drive-440V-5HP.aspx
®
Micro Drive FC 51 Programming Guide
Change During Conversi
Default Value 2 Setup
Operation on Index
[0] Digital and ctrl.word All set-ups TRUE
[1] FC RS485 All set-ups TRUE
1 s 1 set-up TRUE
[0] Off 1 set-up TRUE
[0] No function 1 set-up TRUE
[0] FC 1 set-up TRUE
1 1 set-up TRUE
[2] 9600 Baud 1 set-up TRUE
[0] Even Parity 1 Stop Bit 1 set-up TRUE
0.01 s 1 set-up TRUE
5 s 1 set-up TRUE
0 1 set-up TRUE
[3] Logic OR All set-ups TRUE
[3] Logic OR All set-ups TRUE
[3] Logic OR All set-ups TRUE
[3] Logic OR All set-ups TRUE
[3] Logic OR All set-ups TRUE
[3] Logic OR All set-ups TRUE
[3] Logic OR All set-ups TRUE
0 All set-ups TRUE
Change During Conversi
Default Value 2 Setup
Operation on Index
[0] Off 1 set-up TRUE
[39] Start command 1 set-up TRUE
[40] Drive stopped 1 set-up TRUE
[0] Do not reset 1 set-up TRUE
[0] Disabled 1 set-up TRUE
[1] ApproxEqual 1 set-up TRUE
0 1 set-up TRUE
0 s 1 set-up TRUE
[0] False 1 set-up TRUE
[0] Disabled 1 set-up TRUE
[0] False 1 set-up TRUE
[0] Disabled 1 set-up TRUE
[0] False 1 set-up TRUE
[0] False 1 set-up TRUE
[0] Disabled 1 set-up TRUE
®
is a registered Danfoss trademark
Type
- Uint8
- Uint8
-1 Uint16
- Uint8
- Uint8
0 Uint8
0 Uint8
- Uint8
- Uint8
-3 Uint16
-3 Uint16
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
0 Int16
Type
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
-1 Int32
-1 Uint32
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
- Uint8
