4.13.6. ANALOG OUTPUT CONFIGURATION

Toggle this button
to turn AUTO CAL
calibration mode).
Note
146
Analog calibration needs to be carried out on first startup of the analyzer (performed in
the factory as part of the configuration process) or whenever recalibration is required.
The analog outputs can be calibrated automatically, either as a group or individually
(Section 4.13.6.1), or adjusted manually (see Section 4.13.6). (Manual calibration should
be used for the 0.1V range or in cases where the outputs must be closely matched to the
characteristics of the recording device. Manual calibration requires the AUTOCAL
feature to be disabled).During automatic calibration the analyzer tells the output
circuitry to generate a zero mV signal and high-scale point signal (usually about 90% of
chosen analog signal scale) then measures actual signal of the output. Any error at zero
or high-scale is corrected with a slope and offset.
To enable or disable the Auto-Cal feature for one output channel, press.
AIO CONFIGURATION SUBMENU
DIAG
PREV NEXT
DIAG AIO
SET>
Continue pressing SET> until you reach the
DIAG AIO
<SET SET>
DIAG AIO
SET>
Continue pressing SET> until ...
DIAG AIO
<SET SET>
DIAG AIO
ON
ON or OFF
(OFF = manual
DIAG AIO
OFF
Channels with current loop output options cannot be calibrated automatically.
Outputs Configured for 0.1V full scale should always be calibrated manually.
Teledyne API - Model T200H/T200M Operation Manual
From the
(in the SETUP DIAG menu)
ANALOG I/O CONFIGURATION
ENTR EXIT
AOUTS CALIBRATED: NO
CAL EXIT
output to be configured
DATA_OUT_3: 5V, NXCNC1, NOCAL
EDIT EXIT
DATA_OUT_3 RANGE: 5V
EDIT EXIT
DATA_OUT_3 AUTO CAL.:ON
EDIT EXIT
DATA_OUT_3 AUTO CAL.:ON
ENTR EXIT
DATA_OUT_3 AUTO CAL.:OFF
ENTR EXIT
ENTR accepts
the new setting.
EXIT ignores the
new setting
