Install a DIMM

14. To lock the cover, slide it toward the front of the CMOD until it locks into place.
This action is accompanied by an audible click.
"Install a CMOD" on page 143
Next Steps ■
Install a DIMM
Use this procedure to install DIMMs for a memory upgrade or a configuration change or as part
of a DIMM reset (removal and installation).
For component serviceability, locations, and designations, see
Before You Begin ■
Designations" on page
"Remove a DIMM" on page 155
■
1. Prepare the server for warm or cold service. See
Service" on page 96
Remove the CMOD. See
2.
To remove the CMOD top cover, push the release button, slide the CMOD cover
3.
toward the back of the CMOD, and lift it away.
See "Remove and Install the CMOD Cover" on page
152 Oracle Server X5-8 Service Manual • December 2015
79.
or "Prepare the Server for Cold Service" on page
"Remove a CMOD" on page
"Component Locations, and
"Prepare the Server for Warm
137.
140.
98.
