Storage and IO Subsystem

The server storage and input/ouput subsystem consists of the following:
8 or 16 PCIe Gen3 IO slots (up to eight 16-lane + eight 8-lane)
■
8 SAS2/SATA3 HDD or SSD SFF drive
■
Two 1G/100/10 Ethernet ports
■
4 USB 2.0 ports (2 external, 2 internal)
■
Back Panel Ports and Connectors
The following figure shows the back panel ports and connectors.
Server Subsystems
Server and Components Overview 45
