Remove A Cmod - Oracle X5-8 Service Manual

"Install a DIMM" on page 152
■
"Remove a DIMM" on page 155
■
"Memory and DIMM Reference" on page 158
■
"Remove a Heatsink and Processor (FRU)" on page 161
■
"Install a Heatsink and Processor (FRU)" on page 172
■

Remove a CMOD

You need to remove the CMOD to service it or its internal components.
For component serviceability, locations, and designations, see
Before You Begin
Designations" on page
1. Prepare the server for warm or cold service. See
Service" on page 96
2. Identify which group of fan modules (left or right) to remove to access the
CMOD.
CMODs 0-3 are in the leftmost group, and CMODs 4-7 are in the rightmost group. If you know
the group, then you know which group of four fan modules to remove. If you are removing a
CMOD in a failed state, the lit fault indicator for the CMOD on the FIM shows you the CMOD
number and the group to which it belongs.
In a four-CMOD configured server, remove the leftmost group of fans.
3. Remove the fan modules. See
4. Remove the fan frame. See
5. Identify the CMOD.
79.
or "Prepare the Server for Cold Service" on page
"Remove a Fan Module" on page
"Remove a Fan Frame" on page
Remove a CMOD
"Component Locations, and
"Prepare the Server for Warm
117.
122.
Servicing Components
98.
137
