For component serviceability, locations, and designations, see
Before You Begin ■
Designations" on page
Align the fan module with the slot.
1.
Ensure the handle is positioned at the bottom of the slot with the green release button to the left
and that the air vane for the slot swings freely.
Caution -
the server. Ensure that the connector on the CMOD and the connector on the fan module are
aligned correctly.
2. To install the fan module, slide it into the slot until it stops and gently push it
inward until the fan module locks into place.
The locking action is accompanied by a click sound.
79.
Component damage. Do not apply excessive force when sliding the fan module into
Install a Fan Module
"Component Locations, and
Servicing Components 121
