Advanced Setup Options Options
Internal Port 0 Disabled/ Enabled
Internal Port 1 Disabled/ Enabled
Serial Port Console
Redirection
EMS Console Redirection Disabled/ Enabled
Console Redirection Disabled/ Enabled
Terminal Type VT100/
VT100+/
VT-UTF8/
ANSI
Bits per Second 9600/ 10200
/ 57600/ 115200
Data Bits 07/08/11
Parity None/
Even/
Odd/
Mark/
Space
Stop Bits 01/02/11
Defaults Description
Enabled Enable or disable internal USB Port 0. By
default, internal port 0 is reserved for Oracle
System Assistant.
Enabled Enable or disable internal USB Port 1.
Provides the capability to redirect console
output/input to the serial port. Graphic
output is not redirected. BIOS serial console
redirection lets you monitor BIOS POST
messages and navigate the BIOS Setup
utility menus and Option ROMs from a
terminal connected to the server using a
serial connection.
Disabled Enable or disable console redirection for
Windows Emergency Management Service
(EMS) administration.
Enabled Enable or disable console redirection.
VT100+ Select the emulation for the terminal:
VT100: ASCII character set. VT100+:
Extends VT100 to support color, function
keys, etc. VT-UTF8: Uses UTF8 encoding
to map Unicode characters onto one or more
bytes. ANSI: Extended ASCII character set.
9600 Select the serial port transmission speed. The
speed must be matched on the connecting
serial device. Long or noisy lines require
lower speeds.
8 Select the data bits.
None A parity bit can be sent with the data bits to
detect some transmission errors.
None: No parity bits are sent.
Even: Parity bit is 0 if the number of 1s in
the data bits is even.
Odd: Parity bit is 0 if the number of 1s in the
data bits is odd.
Mark: Parity bit is always 1.
Space: Parity bit is always 0.
Mark and Space parity do not allow for error
detection. They can be used as an additional
data bit.
1 Stop bits indicate the end of a serial data
packet. (A start bit indicates the beginning of
a serial data packet.) The standard setting is
BIOS Setup Utility Screens
