Install a Heatsink and Processor (FRU)
Caution -
push on it.
9.
Close the CPU load plate.
10.
Lower and lock the right side lever, ensuring that the lever is secured under its
retaining clip and that the bend in the lever locks the cover plate.
The right side lever must be closed first.
176
Oracle Server X5-8 Service Manual • December 2015
Equipment Damage. Once the processor sits evenly in the socket, do not move it or
