Remove the HBA Card
This is an internal component that is accessible from the rear of the server by removing the
SMOD. The host bus adapter (HBA) card is installed in an internal PCIe slot mounted on the
SMOD motherboard. Perform this procedure to replace the HBA card.
For component serviceability, locations, and designations, see
Before You Begin
Designations" on page
Prepare the server for cold service. See
1.
Service" on page
2. Remove the SMOD. See
3. Set the SMOD on a flat surface with the front side facing toward you.
4. Close the SMOD handles.
5. Rotate the SMOD 180 degrees so the back (connector) side is facing toward you.
6. Turn the SMOD upside down and locate the HBA.
Note -
The HBA is located inside the SMOD and is accessible through the an upward-facing opening
on the right side. In the following illustration, call out 1 shows the locking lever and callout 2
shows the location of the HBA card.
79.
98.
"Remove the SMOD" on page
The connector (back) side of the SMOD should still be facing you.
"Component Locations, and
"Prepare the Server for Cold
197.
