Prepare the Server for Warm Service

1. Log in to the service processor Oracle ILOM web interface.
Direct a web browser to Oracle ILOM using the IP address of the server SP and log in as root or
a as user with administrator privileges. See
The Summary screen appears.
2. In the Actions section of the Summary screen, click the Locator Indicator Turn
On button.
This action activates the Locator indicator on the server front panel. For other options, see
"Managing the Locator Indicator" on page
3. Once at the service location, press the Locator button to deactivate the indicator.
For more information, see
4. Set up an ESD-safe space at the service location.
Set up a space where you can set components. The space needs to be ESD safe. See
"Performing Electrostatic Discharge and Static Prevention Measures" on page
"Servicing Fan Modules and Fan Frames" on page 117
Next Steps ■
"Servicing Power Supply Units (PSUs)" on page 126
■
"Servicing Storage Drives" on page 180
■
"Servicing PCIe Cards and the Dual PCIe Card Carriers (DPCCs)" on page 185
■
Prepare the Server for Warm Service
This procedure describes how to prepare the server for warm service, so you can remove and
replace CMODs, DIMMs, and processors and heatsinks without disconnecting the power cords
or shutting down Oracle ILOM.
When Oracle ILOM detects that two fan modules in a single cooling zone (a vertical column)
have been removed, it removes power from the CMODs, allowing you to service CMODs and
their subcomponents without removing the power cords. Oracle ILOM remains available in
warm service mode.
This procedure uses a combination of the Oracle ILOM web and CLI interfaces. However, the
procedure can be performed using only the Oracle ILOM CLI interface (for more information,
refer to the Oracle ILOM documentation).
For more information about component serviceability, see
Requirements" on page
96 Oracle Server X5-8 Service Manual • December 2015
Oracle X5 Series Servers Administration
108.
"Control the Locator Indicator Locally" on page
79.
90.
"Component Serviceability
Guide.
110.
