Performing Electrostatic Discharge and Static Prevention Measures

Name
/SYS/CMOD[0-7]
/SYS/CMOD[0-7]/P[0-7]
/SYS/CMOD[0-7]/P[0-7]/P[0-23]
/SYS/CMOD[0-7]/CPLD
/SYS/BIOS
/SYS/DPCC[0-7]
/SYS/DPCC[0-7]/PCIE[1-16]
/SYS/FIM
Performing Electrostatic Discharge and Static Prevention
Measures
Electrostatic discharge (ESD) sensitive devices, such as the PCIe cards, hard drives, CPUs, and
memory cards, require special handling.

Using an Anti-static Wrist Strap

Wear an anti-static wrist strap when handling components such as disk drive assemblies, circuit
boards, or PCIe cards. When servicing or removing server components, attach an anti-static
strap to your wrist and then to a metal area on the server chassis. If your wrist strap is equipped
with a banana connector, insert it into the grounding socket on the right-hand side of the chassis
front panel.
Following this practice equalizes the electrical potentials between you and the server.
Note -
are included with customer-replaceable units (CRUs), field-replaceable units (FRUs), and
optional components.

Using an Anti-static Mat

In addition to wearing an anti-static wrist strap when handling components, create an ESD-free
work place by using an anti-static mat as a work surface and as a place to set ESD-sensitive
90 Oracle Server X5-8 Service Manual • December 2015
An anti-static wrist strap is not shipped with the servers. However, anti-static wrist straps
Description
CPU modules (dynamic FRUID)
Processors (CPUs) on CMOD (static FRUID)
DIMMs on CMOD MB (dynamic FRUID
CPLDs on CMODs
System BIOS
Dual PCIe card carriers (DPCCs)
PCIe cards
Front indicator module
