Remove an Internal USB Flash Drive

"Remove an Internal USB Flash Drive" on page 216
■
"Install an Internal USB Drive" on page 217
■
Remove an Internal USB Flash Drive
This is an internal component that is accessible from the rear of the server by removing the
SMOD. Perform this procedure to access and remove internal USB flash drives.
Your server might come equipped with a server-specific version of Oracle System Assistant
loaded on a USB flash drive and installed (at the factory) in USB port P0. To use Oracle System
Assistant, the flash drive must be installed in port P0, and it must contain only files specific
to Oracle System Assistant. For more information about Oracle System Assistant, see
System Assistant" on page
For component serviceability, locations, and designations, see
Before You Begin ■
Designations" on page
1. Prepare the server for cold service. See
Service" on page
2. Remove the SMOD. See
3. Set the SMOD on a flat surface with the front side facing toward you.
4. Close the SMOD handles.
5. Rotate the SMOD 180 degrees so the back (connector) side is facing toward you.
6. Turn the SMOD upside down and locate the HBA card.
Note -
The USB flash drive is located inside the SMOD next to the HBA card.
7. To remove a USB drive, pull it out of its slot.
216 Oracle Server X5-8 Service Manual • December 2015
44.
79.
98.
"Remove the SMOD" on page
The connector (back) side of the SMOD should still be facing you.
"Component Locations, and
"Prepare the Server for Cold
197.
"Oracle
