Call Out Description
1 Recessed pinhole button
2 Service Action Required/Locator indicator
3 OK indicator

AC Power Inlet Indicators

Each power inlet on the AC power block at the back of the server has a single green OK
indicator that turns on steady only when the power at the connector is sufficient for the power
supply unit. In the following illustration, call out 1 shows the OK indicator for inlet AC 0.
