1. Prepare the server for cold service. See
Service" on page
2. Remove the SMOD. See
3. Set the SMOD on a flat surface with the front side facing toward you.
4. Close the SMOD handles.
5. Rotate the SMOD 180 degrees so the back (connector) side is facing toward you.
Turn the SMOD upside down and locate the HBA.
6.
The connector (back) side of the SMOD should still be facing you.
Note -
The HBA card is located inside the SMOD and is accessible through the an upward-facing
opening on the right side.
Remove the HBA card and disconnect the SAS cables. See
7.
Card" on page
8. Disconnect the SAS cables from the drive backplane.
Carefully route and remove the SAS cables from the SMOD.
9.
10. Connect the replacement cables to the drive backplane.
11. Route the replacement SAS cables from the backplane to the SMOD
motherboard.
12. Ensure that the connectors are routed under the support bracket.
13. Install the HBA card. See
"Install the SMOD" on page 200
Next Steps ■

Servicing the Internal USB Flash Drives

This section contains procedures for accessing and servicing a USB flash drive installed in the
internal USB ports.
98.
"Remove the SMOD" on page
203.
"Install the HBA Card" on page
"Prepare the Server for Cold
197.
"Remove the HBA
206.
Servicing Components
Replace the SAS Cable
215
