Oracle X5-8 Service Manual page 114

Upgrade the Server from Four to Eight CMODs
In a four-CPU configuration, the four CMOD slots on the right side of the server are vacant.
Call Out
1
2
Open each new CMOD and ensure that the DIMMs are configured correctly and
4.
properly seated in their slots:
Caution -
discharge. Wear a wrist strap and use an anti-static wrist mat.
114 Oracle Server X5-8 Service Manual • December 2015
Description
Four CMODs installed in left bay
Empty right-side bay
Component damage. CMOD components are extremely sensitive to electrostatic
