Remove a Heatsink and Processor (FRU)
2. Remove the CMOD from the server. See
To remove the CMOD top cover, push the release button, slide the CMOD cover
3.
toward the back of the CMOD, and lift it away.
Caution -
discharge. Wear a wrist strap and use an anti-static wrist mat.
4. To verify that the processor has failed, press and hold the Fault Remind button
[1].
The green Charge Status indicator [2] lights if the Fault Remind circuit is operational.
■
The fault remind circuit remains charged for about 10 minutes after power is removed from
the CMOD, either by disconnecting power from the server, or by removing the CMOD from
the chassis. When you press the Fault Remind button, the Charge Status indicator lights if
there is enough power to use the fault remind circuit. Otherwise it remains dark.
162 Oracle Server X5-8 Service Manual • December 2015
Component damage. CMOD components are extremely sensitive to electrostatic
"Remove a CMOD" on page 137.
