Install the FIM

4. To remove the FIM, press and hold the release latch and slide the FIM completely
out of its slot.
"Install the FIM" on page 134
Next Steps ■
Install the FIM
Access this component directly from the front of the server.
For component serviceability, locations, and designations, see
Before You Begin ■
Designations" on page
1. Position the connector end of the FIM at the opening of the slot.
134 Oracle Server X5-8 Service Manual • December 2015
79.
"Component Locations, and
