Call Out Description
0 Slot 0
1 Slot 1
2 Slot 2
3 Slot 3
4 Slot 4
5 Slot 5
6 Slot 6
7 Slot 7
DPCC and PCIe Card Slot Designations
The eight dual PCIe card carrier (DPCC) slots are arranged in a single row at the back of the
server. The slots are designated from right to left as, DPCC 0–DPCC 7.
Each DPCC supports two PCIe slots, for a total of 16. The PCIe slots are designated from right
to left as PCIe 1–PCIe 16.
DPCC 0 contains PCIe slots 1 and 2
■
DPCC 1 contains PCIe slots 3 and 4
■
DPCC 2 contains PCIe slots 5 and 6
■
DPCC 3 contains PCIe slots 7 and 8
■
DPCC 4 contains PCIe slots 9 and 10
■
DPCC 5 contains PCIe slots 11 and 12
■
DPCC 6 contains PCIe slots 13 and 14
■
DPCC 7 contains PCIe slots 15 and 16
■
The following illustration shows the location and designations of the PCIe slots.
Component Locations, and Designations
