Use this procedure to replace or reset a DIMM.
For component serviceability, locations, and designations, see
Before You Begin ■
Designations" on page
Use Oracle ILOM to identify the location of the failed DIMM and obtain CMOD
■
designation information.
For an overview video about replacing a failed DIMM, see
Tip -
1. Prepare the server for warm or cold service. See
Service" on page 96
2. Remove the CMOD that contains the failed DIMM. See
CMOD" on page
3. To remove the CMOD top cover, push the release button, slide the CMOD cover
toward the back of the CMOD, and lift it away.
Caution -
discharge. Wear a wrist strap and use an anti-static wrist mat.
79.
or "Prepare the Server for Cold Service" on page
137.
Component damage. CMOD components are extremely sensitive to electrostatic
Replace a Failed DIMM
"Component Locations, and
Replacing DIMMs.
"Prepare the Server for Warm
"Remove a
Servicing Components
98.
