Oracle X5-8 Service Manual page 249

Advanced Setup Options Options
NET3
Commit
IPv4 Configuration (R/O)
Channel Number (R/O)
IPv4 Assignment (R/O) Static/Dynamic
Current IPv4 Address in
BMC (R/O)
Current IPv4 MAC
Address in BMC (R/O)
Current IPv4 Subnet Mask
in BMC (R/O)
Refresh
IPv4 Address
IPv4 Subnet Mask
IPv4 Default Gateway
Commit
IPv6 Configuration (R/O) Static/Dynamic
Channel Number (R/O)
Current IPv6 State (R/O)
Current IPv6 Auto
Configuration (R/O)
Link Local IPv6 Address
(R/O)
Static IPv6 Address (R/O)
Defaults Description
Commit the current BMC network
information.
Current configuration of the IPv4 settings.
Current channel number.
Static View whether the service processor is
assigned a static IPv4 address or assigned a
dynamic IPv4 address using Dynamic Host
Control Protocol (DHCP).
Current IPv4 address of the service
processor. Example: 172.31.255.255
Current IPv4 MAC address for the service
processor. Example: 00:12:46:BE:0A:02
Current IPv4 subnet mask address for the
service processor. Example: 255.255.255.0
Select Refresh to update to the current
settings.
If IPv4 Assignment is set to Static, set the
IPv4 address for the service processor.
If the IPv4 Assignment is set to Static, set the
IPv4 subnet mask. Example: 255.255.255.0
If the IPv4 Assignment is set to Static,
set the IPv4 default gateway. Example:
129.144.82.254
Commit the IPv4 configuration settings.
Dynamic Current configuration of the IPv6 settings.
IPv6 addresses are written with hexadecimal
digits and colon separators. For example:
2001:0db0:000:82a1:0000:0000:1234:abcd.
IPv6 addresses are composed of two parts:
a 64-bit subnet prefix and a 64-bit host
interface ID. To shorten the IPv6 address,
you can (1) omit all leading zeros, and (2)
replace one consecutive group of zeros with
a double colon (::). For example: 2001:db0:
0:82a1::1234:abcd
1 Current channel number.
Current IPv6 state.
Current IPv6 autoconfiguration parameters
are displayed.
Current link local IPv6 address. Example:
fe80::214:4fff:feca:5f7e/64
Current static IPv6 address. Example: 2001:
0db0:000:82a1:0000:0000:1234:abcd
BIOS Setup Utility Screens
BIOS Setup Utility 249
