Servicing Fan Modules and Fan Frames

This section includes information and procedures for servicing fan modules (FMs) and fan
frames:
"Remove a Fan Module" on page 117
■
"Install a Fan Module" on page 120
■
"Remove a Fan Frame" on page 122
■
"Install a Fan Frame" on page 124
■

Remove a Fan Module

Access fan modules (FMs) from the front of the server. Remove a FM to replace it when it has
failed, or remove it as part of the process for accessing CMODs.
FMs are hot-service components; however, accessing CMODs is a warm or cold-service
procedure. For more information, see
For component serviceability, locations, and designations, see
Before You Begin ■
Designations" on page
Prepare the server for hot service. See
1.
Service" on page
Alternatively, to prepare the server for warm or cold service, see
Service" on page 98
Identify the fan module by its position and designation or, if it is in a failed state,
2.
by its steady on Service Action Required indicator.
"Remove a CMOD" on page
79.
95.
or "Prepare the Server for Warm Service" on page
Servicing Fan Modules and Fan Frames
137.
"Component Locations, and
"Prepare the Server for Hot
"Prepare the Server for Cold
Servicing Components
96.
117
