Replace a DPCC

Replace a DPCC
Perform this procedure to replace a failed DPCC.
For component serviceability, locations, and designations, see
Before You Begin ■
Designations" on page
1. Remove the DPCC. See
2. Remove the PCIe cards. See
3. Install the PCIe cards in the replacement DPCC. See
Card" on page
4. Install the DPCC into the server. See
Note -
DPCC to alert the OS.
"Returning the Server to Operation" on page 235
See Also ■

PCIe Card and DPCC Reference

This section contains reference information for PCIe cards and DPCCs, including DPCC
population rules.
Server PCIe Card Capabilities
The server contains nine low-profile PCIe slots, eight Gen 3 DPCC slots accessible at the
rear of the server and one Gen 2 slot, which is located internally (and not directly accessible)
on the system module (SMOD). This internal slot is used for server HBA and provides SAS
connectivity to the server storage drives.
Dual PCIe Card Carriers (DPCCs)
The server contains eight hot-service PCIe Gen 3 DPCCs. Each DPCC has two low-profile
PCIe Gen 3 slots, an 8-lane slot and a 16-lane slot. Each DPCC can contain up to two PCIe
cards.
196 Oracle Server X5-8 Service Manual • December 2015
79.
"Remove a DPCC" on page
190.
The DPCC install procedure includes instructions for using the ATTN buttons on the
"Remove a PCIe Card" on page
"Install a DPCC" on page
"Component Locations, and
185.
188.
"Install a PCIe
193.
